Locus workbench¶

A browser-based playground for every locus pattern. Two clicks to a running agent — no CLI, no pip install, no editor setup.

Launch in Codespaces View on GitHub

Click 1 — Launch. GitHub provisions a Codespace, installs Python + Node deps, and boots all three tiers (FastAPI runner, Node BFF, Vite front-end). After ~2 minutes the workbench UI opens in a Simple Browser tab.

Click 2 — Run. Open Provider settings, paste an OpenAI or Anthropic key, pick a tutorial in the sidebar, hit Run. A real agent streams events back into the browser.

locus workbench

What it is¶

The workbench is the fastest way to see what locus does without installing anything locally. It's a single-page UI in front of every canonical locus pattern — a basic agent, an agent with tools, a structured-output schema, an orchestrator with specialists, a sequential pipeline, a map-reduce fan-out, a critic loop with allow_cycles. Each pattern is wired to a real Python coroutine that imports locus, builds the agent, and streams events through to your browser.

It's also the canonical demo for Codespaces and Docker: visitors arrive at this app, pick a workflow, and learn the SDK by running real ones.

┌───────────────────────────────────────┐
│  workbench/web   — vanilla TS + Vite  │  :5173
│  Tutorial catalog · provider settings │
└───────────────────┬───────────────────┘
                    │ /api/*
                    ▼
┌───────────────────────────────────────┐
│  workbench/bff   — Node Express       │  :3101
│  Same-origin proxy + cookie surface   │
└───────────────────┬───────────────────┘
                    │ /api/*
                    ▼
┌───────────────────────────────────────┐
│  workbench/backend — FastAPI runner   │  :8100
│  One endpoint per locus pattern       │
└───────────────────────────────────────┘

You paste your provider key once per tab — the workbench never persists API keys to localStorage, so closing the tab discards everything.

Three paths to spin it up¶

Pick whichever fits — Codespaces for zero install, Docker for a local container with BYO key, or From source for iterating on the workbench itself.

Path A — GitHub Codespaces (zero install, free)¶

Click the badge on the repo home page. GitHub provisions a Linux container in your account, runs .devcontainer/postCreate.sh to install Python + Node deps, then forwards port 5173 publicly. ~2-min cold start. You burn your own free Codespaces minutes (60 hrs/month), nothing on the locus side.

Path B — Docker (local, BYO key)¶

git clone https://github.com/oracle-samples/locus.git && cd locus
docker build -t locus-workbench -f workbench/Dockerfile .
docker run --rm -p 5173:5173 -p 3101:3101 -p 8100:8100 locus-workbench
# open http://localhost:5173
# → paste OpenAI / Anthropic key in Provider settings → Run a tutorial

Image is ~1.3 GB on first build (Oracle Linux 9-slim base + Python 3.12 + Node 20 + locus + the workbench source). Subsequent builds hit the layer cache.

Codespaces — what happens after you click¶

Cold start — GitHub builds the container from .devcontainer/devcontainer.json (Python 3.12 + Node 20). First boot runs postCreate.sh to pip install -e ".[dev,llm]" plus fastapi + python-multipart, and npm install both workbench projects against the public npm registry. ~2 minutes.
Two tabs open — GitHub Codespaces opens a VS Code Web tab first (the editor session that owns the container). When Vite binds on :5173, a second tab opens with the workbench UI itself (https://<codespace>-5173.app.github.dev) per 5173.onAutoForward: openBrowserOnce. The workbench is the second tab, not VS Code. If your browser blocks the popup, the VS Code terminal panel shows a clearly-labelled 🚀 locus workbench is ready banner with a ⌘-clickable URL — same destination.
Auto-boot — postStart.sh backgrounds the three tiers in detached setsid sessions so they survive after the lifecycle hook exits: uvicorn runner:app on :8100, npm run dev (Express) on :3101, npm run dev (Vite) on :5173.
Run a pattern — Provider settings → paste an OpenAI or Anthropic key → pick a tutorial → Run.

The OCI options in the Provider settings modal will not work in Codespaces — they need a local ~/.oci/config that doesn't exist in the container. Use OpenAI or Anthropic for the cloud demo path.

Docker — port-remap if 5173 is taken¶

docker run --rm \
  -p 5273:5173 -p 3201:3101 -p 8200:8100 \
  locus-workbench
# then http://localhost:5273

Stop with Ctrl-C; the --rm flag removes the container on exit.

Path C — From source (development)¶

For iterating on the workbench itself:

git clone https://github.com/oracle-samples/locus.git
cd locus
pip install -e ".[server,oci,openai,anthropic]"  # core + extras

# Three terminals, one per tier:
cd workbench/bff && npm install && npm run dev      # :3101
cd workbench/web && npm install && npm run dev      # :5173
cd workbench/backend && python -m uvicorn --app-dir . runner:app --port 8100

Or use the Makefile in workbench/:

cd workbench && make install
make backend   # pane 1 — FastAPI runner on :8100
make bff       # pane 2 — Express BFF on :3101
make web       # pane 3 — Vite dev server on :5173

make install runs npm install for both bff/ and web/ plus npx playwright install chromium for the e2e suite. The backend target is the workbench's FastAPI runner — distinct from backend-research and backend-finance, which spin up the A2A mesh demo peers for tutorial 34, not the workbench itself.

Provider settings¶

The header's Provider settings modal accepts four shapes:

OpenAI — paste sk-… + pick a model (defaults to gpt-5.5).
Anthropic — paste sk-ant-… + pick a model (defaults to claude-sonnet-4-6).
OCI session token — profile (e.g. MY_PROFILE) + compartment_id + region. Reads ~/.oci/config at runtime; needs a valid session token. Local-machine only.
OCI api-key — same shape, different OCI auth type. Local-machine only.

Settings live in the page's memory. Closing the tab discards them. Reopening the page = paste again. This is intentional: an API key sitting in localStorage on a shared computer is a leak waiting to happen.

What you can run¶

The catalog populates from the BFF's /api/tutorials endpoint, which walks examples/tutorial_*.py. As of writing the workbench has 9 dedicated FastAPI pattern endpoints:

Pattern	What it shows
Basic agent	One-shot Q&A — hello world for the SDK
Agent + tools	ReAct loop with `add` and `reverse` tools
Structured output	`output_schema=Verdict` → typed Pydantic result
Orchestrator + specialists	Coordinator dispatches to researcher + editor
Sequential composition	Two agents chained: researcher → summariser
Map-reduce code review	Fan-out to 3 reviewers, reduce findings
StateGraph critic loop	Writer → Critic cycle with `allow_cycles`
Long-term memory	Two-session demo — see below
Cognitive routing	Rule-based vs LLM-picker selection — see below

The rest run as plain Python subprocesses against your provider — same behaviour as running the tutorial from a terminal, just inside the workbench so you can watch streamed events instead of tailing stdout.

Long-term memory pattern¶

Pick Long-term memory in the sidebar and paste a prompt that reveals something about yourself — your role, a preference, a constraint. The workbench runs two back-to-back agent sessions:

Session 1 processes your prompt and runs LLM-backed extraction to identify durable facts worth keeping. Those facts are persisted to an in-memory store (scoped to the request; cleared between runs).

Session 2 is a fresh agent with no conversation history — only the injected [Long-term Memory] block. It answers "What do you know about me?" using only what was stored, demonstrating cross-session recall without passing any raw history.

Sample prompts that produce interesting memory extraction:

I'm a senior Python engineer working on a compliance-driven auth rewrite.
I prefer short answers and always want real database connections in tests —
no mocks. Can you explain JWT vs session tokens briefly?

I'm a data scientist focused on model evaluation. I work in Python and use
Oracle ADB for storage. The project deadline is end of Q2. What's a good
evaluation metric for imbalanced classification?

The reply shows three sections: the Session 1 answer, the extracted memories (key/content pairs), and the Session 2 recall — so you can see exactly what the model chose to remember and how it surfaced in a fresh context.

Cognitive routing pattern¶

Pick Cognitive routing in the sidebar and you'll see a Selection mode segmented control above the Run button:

Rule-based (default) — ProtocolRegistry.select() → deterministic _rank_key tuple comparison. Auditable, reproducible, free of model latency.
LLM picker (opt-in) — LLMProtocolPicker lets the model pick the protocol from the filtered candidate set. PolicyGate, capability binding, and the candidate filter all stay rule-based; only the disambiguation step moves to the model.

Hit Run and the workbench shows a chip with the dispatched protocol_id plus a method badge (rule_based / single_candidate / llm_picked / rule_based_fallback). When LLM-picker mode dispatched the run, the model's one-sentence rationale renders as a callout above the reply text — the same field the router.protocol.selected SSE event carries.

Sample prompts that exercise different protocols:

What does the locus router do in the context of this SDK?
→ direct_response

Compare swarm vs orchestrator patterns for open-ended research.
→ debate (LLM picker may differ from the rule-based ranker)

Diagnose the checkout API latency spike: pull metrics, list alerts,
correlate findings.
→ specialist_fanout

See tutorial 59 for the full code path and concepts/router.md for the architectural details.

Cost¶

You pay $0 when someone uses the workbench. Each visitor's compute hits their own free GitHub / their own Docker, and their model calls hit their own provider key. Oracle pays $0 unless an oracle-employee opens it AND oracle-samples org Codespaces billing is enabled.

Troubleshooting¶

Sidebar is empty — BFF couldn't reach the backend. Check docker logs <container> or the runner pane: usually means the backend hasn't finished starting yet (10-20s on cold boot).
"Provider settings: setup required" never goes away — you closed the modal without hitting Save. Reopen and click Save.
OCI session-token auth says "no profile" — you're running in Codespaces / Docker; OCI auth needs ~/.oci/config mounted in. Switch to OpenAI or Anthropic.
Tutorial fails with "no parsed Pydantic" / empty output — your model is too small for structured output. Use gpt-5.5-2026-04-23, gpt-4o, or claude-sonnet-4-6 for the demos that use output_schema.
